Crimped Wire Mesh

Crimped Wire Mesh: Black Steel, 304, 430, & Intermediate-Crimp

We offer a wide range of customizable crimped wire mesh for industrial and commercial use, including black steel, 304 stainless steel (2mm wire, 12mm x 12mm openings), 10-gauge (Ø 0.135″) intermediate-crimp steel, 430 stainless steel, and specialized “crimped wire 007” (240N hole spacing, 28-inch width). These meshes are designed for high structural strength, rigidity, anti-slip surfaces, and resistance to deformation, with plain, intermediate, and lock-crimp styles available. They are used in mining screens, quarry sieves, fencing, safety barriers, BBQ grills, filtration systems, and architectural panels, providing solutions for heavy-duty and fine screening applications.
Crimped Wire Mesh

Mallas exporting Stainless Steel Crimped Wire Mesh. Stainless steel crimped wire mesh is categorized by material grade (304, 316, 430), weave pattern (plain, intermediate, lock crimp), and intended use. These grades offer excellent corrosion resistance and durability in demanding settings. The weave patterns affect rigidity and grip, while wire diameter and opening size dictate screening capabilities. Applications include mining, construction, filtration, food processing, and architectural design, leveraging its strength and stability.

Technical Data – Black Steel Crimped Mesh

Black steel crimped mesh is a durable and versatile material widely used in industrial applications. It is made out of high tensile wire, providing excellent strength and structural stability.

Y.S.Wire DiaApertureWidth mmLength mmMOQ
650N/mm24mm12mm2.42.2200
650N/mm23mm12mm2.42.2200
650N/mm23mm10mm2.42.2200

“Y.S.” stands for Yield Strength

  • Yield Strength is a material property defined as the stress at which a material begins to deform plastically. Before the yield strength is reached, the material will deform elastically and will return to its original shape when the applied stress is removed. Once the yield1 strength is passed, some permanent deformation will occur.
Durable Black Steel Crimped Mesh for Industrial Applications

TDS: SS304 Crimped Wire Mesh – 2mm Wire, 12×12 mm Opening

  • Wire Diameter: 2.0 mm
  • Opening Size: 12 mm × 12 mm (centre-to-centre, ±0.5 mm tolerance)
  • Mesh Count: Approx. 2.1 openings per inch
  • Open Area: Approx. 64%
  • Crimp Style: Double crimp (standard), intermediate or lock crimp (upon request)
  • Crimp Dimensions:
    Crimp Depth: 1.5 mm
    Crimp Pitch: 6.0 mm
  • Sheet Size: Customizable (e.g., 1m × 2m, 1.2m × 2.4m, or as specified)
  • Edge Finish: Cut edge or welded edge (optional)
  • Surface Finish: Mill finish
  • Weight: Approx. 4.24 kg/m²

Product Specification Sheet: Intermediate Crimp Steel Wire Mesh – 10 Gauge, 12×12 mm Opening

  • Material: Carbon Steel (Intermediate Crimp)
  • Wire Gauge: 10-Gauge
  • Wire Diameter: Ø 0.135 inch (≈ 3.43 mm)
  • Opening Size: 12 mm × 12 mm (center-to-center)
  • Mesh Type: Woven, Intermediate Crimp Style
  • Overall Thickness: Approx. 5 mm (includes wire crimp height)
  • Panel Size: 4 ft × 8 ft (≈ 1.22 m × 2.44 m)
  • Surface Finish: Mill finish (galvanized or powder-coated available upon request)
  • Crimp Style: Intermediate crimp – providing enhanced rigidity and structure
  • Edge Finish: Raw edge; trimmed or welded edge available upon request
  • Weight per Panel (approx.): ~12–15 kg (depending on crimp depth and wire spacing)
  • Open Area: Approx. 64%
  • Applications: Quarry screens, fencing, safety barriers, industrial sieving, architectural panels
  • MOQ: Approx. 50 pieces
  • Packaging: Palletized or bundled with protective wrapping
10 Gauge Intermediate Carbon Steel Crimped Wire Mesh

430ss wire mesh, “crimped wire 007” x hole 240N x roll width 28

430 Stainless Steel Crimped Wire Mesh – 7 mm Opening, 28-Inch Roll Width

  • Material: 430 Stainless Steel
  • Mesh Type: Crimped Wire Mesh
  • Opening Size: 7 mm × 7 mm (center-to-center)
  • Roll Width: 28 inches (≈ 711 mm)
  • Crimp Style: Intermediate or double crimp (as specified)
  • Wire Diameter: Specify (e.g., 1.0 mm, 1.5 mm, etc.)
  • Roll Length: Customizable (e.g., 10 m, 25 m, or 30 m)
  • Surface Finish: Mill finish (galvanized optional)

Material Properties – 430 Stainless Steel

  • Corrosion Resistance: Moderate; suitable for indoor or dry environments
  • Magnetic: Yes
  • Tensile Strength: Approx. 450–600 MPa
  • Operating Temperature: Up to 815°C (1500°F)
  • Density: 7.7–7.8 g/cm³

Applications

  • Industrial and food-grade filtration
  • Protective panels and machine guards
  • Ventilation grilles
  • Sieving and screening in mild environments
  • Decorative and architectural uses

Customized Sizes

This diverse range in material, size, and customization makes Stainless Steel Crimped Wire Mesh a versatile solution for numerous industrial, architectural, and specialized applications.

MeshOpen AreaWire DiameterWeaving methods
inchmmMax(mm)Min(mm)
4″4101.612.76Intercrimp/Lock
3″376.212.75Intercrimp/Lock
2″250.8104Intercrimp/Lock
1 1/2″238.1103Intercrimp/Lock
1X2″1X225.4X50.882.5Intercrimp/Lock
1″125.482Plain /Intercrimp
3X4″0.7519.0561.8Plain /Intercrimp
5X8″0.6215.851.5Plain /Intercrimp
20.512.741Plain /Intercrimp
30.338.4631Plain /Intercrimp
40.256.3520.8Plain /Intercrimp
50.25.081.60.7Plain /Intercrimp
60.174.231.50.6Plain /Intercrimp
80.123.171.20.7Plain /Intercrimp
100.12.5410.6Plain
120.082.110.90.5Plain
140.071.810.70.5Plain
